A Main Power Traffic Controller is a central control system designed to manage traffic signal lights at intersections, highways, and urban road networks.
It coordinates red, yellow, and green signals, pedestrian crossings, and optional auxiliary signals (turn arrows, emergency lights) to optimize traffic flow.
Powered by main AC electricity, this controller ensures reliable, continuous operation and can integrate with advanced traffic management systems for smart city applications.
Controls multiple traffic signals at intersections, coordinating timing for smoother vehicle and pedestrian flow.
Powered directly from the main AC supply for continuous operation without dependence on solar or batteries.
Supports:
Fixed-time mode
Traffic-actuated mode (sensor-based)
Pedestrian signal integration
Emergency vehicle preemption
User-friendly interface allows timing adjustments, sequence programming, and operational monitoring.
Can integrate with:
Turn signals
Pedestrian push buttons
Speed detection systems
Adaptive traffic management systems
Enclosure made from steel or aluminum with IP54–IP65 protection ensures reliable operation in outdoor and semi-outdoor environments.
Optimized control reduces unnecessary power usage while maintaining reliable operation.
Reduces congestion, accidents, and waiting time by coordinating signals effectively.
Power Supply: AC 220V ±10%, 50/60Hz
Signal Outputs: 8–96 channels (expandable)
Control Modes: Fixed-time, sensor-actuated, emergency override
Enclosure Material: Powder-coated steel or aluminum
Protection Rating: IP54–IP65
Operating Temperature: -20°C to +60°C
Mounting: Indoor/outdoor traffic cabinet or roadside kiosk
Programming: Manual keypad, PC software, or remote access
Communication: RS485 / TCP/IP / Wireless optional
